New 2025 Ford E-Series Cutaway
Details
Available
Contact Us About This
New White 2025 Ford E-Series Cutaway
This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.
Description
Vehicle Highlights
- ENGINE: 7.3L V8 PREMIUM-RATED
- OXFORD WHITE
Standard Features
- 4-Wheel Disc Brakes w/4-Wheel ABS, Front Vented Discs and Hill Hold Control
- 4.10 Axle Ratio
- 50 State Emission System
- 78-Amp/Hr 750CCA Maintenance-Free Battery
- Engine: 7.3L V8 Premium-Rated
- Front Suspension w/Coil Springs
- HD 210 Amp Alternator
- HD Shock Absorbers
- Hydraulic Power-Assist Steering
- Rear-Wheel Drive
- Single Stainless Steel Exhaust
- Solid Axle Rear Suspension w/Leaf Springs
- Transmission: 6-Speed O/D w/Tow Haul -inc: auxiliary cooler
- 2 12V DC Power Outlets
- 4-Way Driver Seat -inc: Manual Recline and Fore/Aft Movement
- 4-Way Passenger Seat -inc: Manual Recline and Fore/Aft Movement
- Analog Appearance
- Driver And Front Passenger Armrests
- Driver And Passenger Door Bins
- Dual High Back Buckets
- Engine Cover Console w/Storage and 2 12V DC Power Outlets
- Fixed Antenna
- Fixed Front Head Restraints
- Fleet Telematics Modem Selective Service Internet Access
- Fleet Telematics Modem Tracker System
- Front Cupholder
- Front Only Vinyl/Rubber Floor Covering
- Front Vinyl Headliner
- Gauges -inc: Speedometer, Odometer, Voltmeter, Oil Pressure, Engine Coolant Temp, Tachometer and Trip Odometer
- Glove Box
- Manual 1st Row Windows
- Manual air conditioning
- Manual Tilt/Telescoping Steering Column
- Radio: AM/FM Stereo w/Clock Display & 2 Speakers -inc: Bluetooth® capability and USB input
- Regular Dome Lighting
- Urethane Gear Shifter Material
- Vinyl Bucket Seats
- Auto On/Off Reflector Halogen Daytime Running Lights Preference Setting Headlamps
- Black door handles
- Black Front Bumper w/Black Rub Strip/Fascia Accent
- Black Grille
- Black Side Windows Trim and Black Front Windshield Trim
- Clearcoat Paint
- Front Windshield -inc: Sun Visor Strip
- Fully Galvanized Steel Panels
- Light Tinted Glass
- Variable Intermittent Wipers
- ABS And Driveline Traction Control
- Dual Stage Driver And Passenger Front Airbags
- Electronic Stability Control (ESC) Electronic Stability Control (ESC)
- Outboard Front Lap And Shoulder Safety Belts -inc: Height Adjusters and Pretensioners
- Side Impact Beams
- Vehicle Name: Ford E-Series Cutaway
- Body Style: Chassis
- Body Code: H
- Drivetrain: Rear Wheel Drive
- Passenger Capacity: 1, 2
- Base Curb Weight: 5216, 5217, 5217, 5218, 5219, 5220, 5220, 5220, 5222, 5223, 5225, 5229, 5229, 5229, 5236, 5237, 5238, 5243, 5283, 5288, 5323, 5345, 5381
- Gross Axle Wt Rating – Front: 4200, 4600, 5000
- Gross Axle Wt Rating – Rear: 7800, 8500
- Curb Weight – Front: 3048
- Curb Weight – Rear: 2168
- Gross Vehicle Weight Rating Cap: 11500, 12500
- Gross Combined Wt Rating: 18500
- Dead Weight Hitch – Max Trailer Wt.: 5000
- Dead Weight Hitch – Max Tongue Wt.: 500
- Wt Distributing Hitch – Max Trailer Wt.: 6000, 7000
- Wt Distributing Hitch – Max Tongue Wt.: 600, 700
- Maximum Trailering Capacity: 6000, 7000
- Engine Order Code: 99N
- Engine Type: Regular Unleaded V-8
- Displacement: 7.3 L/445
- Fuel System: Sequential MPI
- SAE Net Horsepower @ RPM: 325 @ 3750
- SAE Net Torque @ RPM: 450 @ 3750
- Trans Order Code: 44P
- Trans Type: 6
- Trans Description Cont.: Automatic w/OD
- Trans Description Cont. Again:
- First Gear Ratio (:1): 3.97
- Second Gear Ratio (:1): 2.32
- Third Gear Ratio (:1): 1.52
- Fourth Gear Ratio (:1): 1.15
- Fifth Gear Ratio (:1): 0.86
- Sixth Gear Ratio (:1): 0.67
- Reverse Ratio (:1): 3.13
- Trans PTO Access: No
- Transfer Case Model: None
- Transfer Case Power Take Off: No
- Cold Cranking Amps @ 0° F (Primary): 750
- Cold Cranking Amps @ 0° F (2nd): 750
- Maximum Alternator Capacity (amps): 210, 240 & 157, 240
- Engine Oil Cooler: None
- Suspension Type – Front: Other
- Suspension Type – Rear: Leaf
- Spring Capacity – Front: 4200, 4600, 5000
- Spring Capacity – Rear: 7800, 8500
- Axle Type – Front: Independent
- Axle Type – Rear: Rigid Axle
- Axle Capacity – Front: 5000
- Axle Capacity – Rear: 8500
- Axle Ratio (:1) – Front: 4.10, 4.56
- Axle Ratio (:1) – Rear: 4.10, 4.56
- Front Tire Order Code: T68
- Rear Tire Order Code: T68
- Spare Tire Order Code: , 51A
- Front Tire Size: LT225/75SR16
- Rear Tire Size: LT225/75SR16
- Spare Tire Size: , Full-Size
- Front Tire Capacity: 5000
- Rear Tire Capacity: 9880
- Revolutions/Mile @ 45 mph – Front: 709
- Revolutions/Mile @ 45 mph – Rear: 709
- Front Wheel Size: 16 X 6
- Rear Wheel Size: 16 X 6
- Spare Wheel Size: , Full-Size
- Front Wheel Material: Steel
- Rear Wheel Material: Steel
- Spare Wheel Material: , Steel
- Steering Type: Re-Circulating Ball
- Turning Diameter – Curb to Curb: 54.8
- Brake Type: 4-Wheel Disc
- Brake ABS System: 4-Wheel
- Brake ABS System (Second Line): 4-Wheel
- Disc – Front (Yes or ): Yes
- Disc – Rear (Yes or ): Yes
- Front Brake Rotor Diam x Thickness: 13.6
- Rear Brake Rotor Diam x Thickness: 13.6
- Drum – Rear (Yes or ):
- Rear Drum Diam x Width:
- Fuel Tank Capacity, Approx: 40, 55
- Front Head Room: 42
- Front Leg Room: 42.1
- Front Shoulder Room: 68.1
- Front Hip Room: 65.6
- Wheelbase: 158
- Length, Overall: 261.1
- Width, Max w/o mirrors: 79.4
- Height, Overall: 80.2
- Overhang, Rear w/o bumper: 68.5
- Cab to Axle: 100
- Cab to End of Frame: 168.5
- Ground to Top of Load Floor: 26.2
- Country of Origin: United States Ford Incomplete Vehicle
- Engine Displacement Units: 7.3, 7.3
- Engine Camshaft: OHV, OHV
- Engine Block Type: iron, iron
- Engine Cylinder Count: 8, 8
- Engine Valve Count: 2, 2
