2024 Chevrolet 5500 XD LCF Diesel
VIN #:JALEEW160R7309385
Stock #:R7309385
Condition:
New
Located at:
Five Star Chevrolet
Add Your Heading Text Here
star_border
star
Save
About this New 2024 Chevrolet 5500 XD LCF Diesel
Trans.:Aisin 6-Speed Automatic
Drivetrain:Rear Wheel Drive
Condition:
5.2L 4 Cylinder 16V
Fuel Type:Diesel
Ext. Color:Arc White
Int. Color:Gray
Research Tools
Description
Price includes: $1500 – Customer Cash. Exp. 01/02/2025 New Feature.
2024 Chevrolet 5500 XD LCF Diesel 5.2L 4 Cylinder 16V Aisin 6-Speed Automatic RWD
***Dealer add ons and accessories are not included in the advertised price. Visit us at www.sampacksfivestarchevrolet.com for more details.
This 2024 Arc White Chevrolet 5500 XD LCF Diesel RWD is well equipped and includes these features and benefits:
Preferred Equipment Group 1WT, 2 Speakers, 2 Speakers Audio System, 4-Wheel Disc Brakes, ABS brakes, Air Conditioning, AM/FM radio, AM/FM Stereo w/Seek & Scan, Back-Up Alarm, Bumpers: body-color, CD player, Driver door bin, Dual rear wheels, Electronic Stability Control, Fire Extinguisher & Safety Reflector, Forward Collision Alert & Lane Departure Warning, Front anti-roll bar, Front Bucket Seats, Front Center Armrest, Mirror Bracket Extension, Overhead console, Passenger door bin, Power steering, Power Take Off Engine Control Provisions, Power windows, Radio: AM/FM Stereo w/CD Player & Bluetooth®, Rear Vision Camera, Remote Keyless Entry, Single-Zone Manual Air Conditioning, Speed control, Tachometer, Telescoping steering wheel, Tilt steering wheel, Traction control, Tricot Cloth Seat Trim, Trip computer, and Wheels: 19.5″ x 6.0″ K Steel.
2024 Chevrolet 5500 XD LCF Diesel 5.2L 4 Cylinder 16V Aisin 6-Speed Automatic RWD
***Dealer add ons and accessories are not included in the advertised price. Visit us at www.sampacksfivestarchevrolet.com for more details.
This 2024 Arc White Chevrolet 5500 XD LCF Diesel RWD is well equipped and includes these features and benefits:
Preferred Equipment Group 1WT, 2 Speakers, 2 Speakers Audio System, 4-Wheel Disc Brakes, ABS brakes, Air Conditioning, AM/FM radio, AM/FM Stereo w/Seek & Scan, Back-Up Alarm, Bumpers: body-color, CD player, Driver door bin, Dual rear wheels, Electronic Stability Control, Fire Extinguisher & Safety Reflector, Forward Collision Alert & Lane Departure Warning, Front anti-roll bar, Front Bucket Seats, Front Center Armrest, Mirror Bracket Extension, Overhead console, Passenger door bin, Power steering, Power Take Off Engine Control Provisions, Power windows, Radio: AM/FM Stereo w/CD Player & Bluetooth®, Rear Vision Camera, Remote Keyless Entry, Single-Zone Manual Air Conditioning, Speed control, Tachometer, Telescoping steering wheel, Tilt steering wheel, Traction control, Tricot Cloth Seat Trim, Trip computer, and Wheels: 19.5″ x 6.0″ K Steel.
Disclaimer
VEHICLE DATA
Certain specifications, prices and equipment data have been provided under license from Chrome Data Solutions (\’Chrome Data\’). © 2024 Chrome Data Solutions, LP. All Rights Reserved. This information is supplied for personal use only and may not be used for any commercial purpose whatsoever without the express written consent of Chrome Data. Chrome Data makes no guarantee or warranty, either expressed or implied, including without limitation any warranty of merchantability or fitness for particular purpose, with respect to the data presented here. All specifications, prices and equipment are subject to change without notice.
ESTIMATE MPG
EPA mileage ratings are supplied by Chrome Data Solutions, LP for comparison purposes only. Your actual mileage will vary, depending on how you drive and maintain your vehicle, driving conditions, battery pack age/condition (hybrid models only) and other factors.
Based on 2019 EPA mileage ratings. Your MPGe/MPG and driving range will vary depending on driving conditions, how you drive and maintain your vehicle, battery-pack age/condition, and other factors.
PRICING
Vehicle pricing is believed to be accurate. Tax, title and registration are not included in prices shown unless otherwise stated. Manufacturer incentives may vary by region and are subject to change. Vehicle information & features are based upon standard equipment and may vary by vehicle. Monthly payments may be higher or lower based upon incentives, qualifying programs, credit qualifications, residency & fees. No claims, or warranties are made to guarantee the accuracy of vehicle pricing, payments or actual equipment. Call to confirm accuracy of any information.
2024 Chevrolet 5500 XD LCF Diesel
VIN #:JALEEW160R7309385
Stock #:R7309385
Condition:
New
Located at:
Five Star Chevrolet
1735 S Interstate 35E
Carrollton, TX 75006
Add Your Heading Text Here
star_border
star
Save
star_border
star
New 2024 Chevrolet 5500 XD LCF Diesel
VIN: JALEEW160R7309385
$59,213
Details
Drivetrain:Rear Wheel Drive
Ext. Color:Arc White
Int. Color:Gray
Trans.:Aisin 6-Speed Automatic
Fuel Type:Diesel
Engine:4 Cylinders
Stock #:R7309385
VIN:JALEEW160R7309385
Available
at Five Star Chevrolet
Five Star Price
$78,713Five Star Discount
-$18,000Internet Price
$60,713Customer Cash **
-$1,500Customer Cash,$1500,Expires 01/02/2025.
Rebate ID: 960
** Not all customers will qualify
See dealer for qualifications and complete details.
Final Price
$59,213
Contact Us About This
New Arc White 2024 Chevrolet 5500 XD LCF Diesel
This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.
Description
Price includes: $1500 – Customer Cash. Exp. 01/02/2025 New Feature.
2024 Chevrolet 5500 XD LCF Diesel 5.2L 4 Cylinder 16V Aisin 6-Speed Automatic RWD
***Dealer add ons and accessories are not included in the advertised price. Visit us at www.sampacksfivestarchevrolet.com for more details.
This 2024 Arc White Chevrolet 5500 XD LCF Diesel RWD is well equipped and includes these features and benefits:
Preferred Equipment Group 1WT, 2 Speakers, 2 Speakers Audio System, 4-Wheel Disc Brakes, ABS brakes, Air Conditioning, AM/FM radio, AM/FM Stereo w/Seek & Scan, Back-Up Alarm, Bumpers: body-color, CD player, Driver door bin, Dual rear wheels, Electronic Stability Control, Fire Extinguisher & Safety Reflector, Forward Collision Alert & Lane Departure Warning, Front anti-roll bar, Front Bucket Seats, Front Center Armrest, Mirror Bracket Extension, Overhead console, Passenger door bin, Power steering, Power Take Off Engine Control Provisions, Power windows, Radio: AM/FM Stereo w/CD Player & Bluetooth®, Rear Vision Camera, Remote Keyless Entry, Single-Zone Manual Air Conditioning, Speed control, Tachometer, Telescoping steering wheel, Tilt steering wheel, Traction control, Tricot Cloth Seat Trim, Trip computer, and Wheels: 19.5″ x 6.0″ K Steel.
2024 Chevrolet 5500 XD LCF Diesel 5.2L 4 Cylinder 16V Aisin 6-Speed Automatic RWD
***Dealer add ons and accessories are not included in the advertised price. Visit us at www.sampacksfivestarchevrolet.com for more details.
This 2024 Arc White Chevrolet 5500 XD LCF Diesel RWD is well equipped and includes these features and benefits:
Preferred Equipment Group 1WT, 2 Speakers, 2 Speakers Audio System, 4-Wheel Disc Brakes, ABS brakes, Air Conditioning, AM/FM radio, AM/FM Stereo w/Seek & Scan, Back-Up Alarm, Bumpers: body-color, CD player, Driver door bin, Dual rear wheels, Electronic Stability Control, Fire Extinguisher & Safety Reflector, Forward Collision Alert & Lane Departure Warning, Front anti-roll bar, Front Bucket Seats, Front Center Armrest, Mirror Bracket Extension, Overhead console, Passenger door bin, Power steering, Power Take Off Engine Control Provisions, Power windows, Radio: AM/FM Stereo w/CD Player & Bluetooth®, Rear Vision Camera, Remote Keyless Entry, Single-Zone Manual Air Conditioning, Speed control, Tachometer, Telescoping steering wheel, Tilt steering wheel, Traction control, Tricot Cloth Seat Trim, Trip computer, and Wheels: 19.5″ x 6.0″ K Steel.
Vehicle Highlights
- ARC WHITE
- ENGINE, DIESEL 5.2L 4 CYLINDER
Standard Features
- Vehicle Name: Chevrolet 5500 XD LCF Diesel
- Body Style: Regular Cab Chassis Cab
- Body Code:
- Drivetrain: Rear Wheel Drive
- Passenger Capacity: 3
- Number of Passenger Doors: 2
- Gross Axle Wt Rating – Front: 7275
- Gross Axle Wt Rating – Rear: 13660
- Curb Weight – Front: 4395
- Curb Weight – Rear: 2281
- Gross Vehicle Weight Rating Cap: 19500
- Gross Combined Wt Rating: 25500
- Engine Order Code: I1B
- Engine Type: Turbocharged Diesel I4
- Displacement: 5.2L/317
- Fuel System: Direct Injection
- SAE Net Horsepower @ RPM: 215 @ 2500
- SAE Net Torque @ RPM: 452 @ 1850-2750
- Trans Order Code: IR7
- Trans Type: 6
- Trans Description Cont.: Automatic
- Trans Description Cont. Again:
- First Gear Ratio (:1): 3.742
- Second Gear Ratio (:1): 2.00
- Third Gear Ratio (:1): 1.343
- Fourth Gear Ratio (:1): 1.000
- Fifth Gear Ratio (:1): 0.773
- Sixth Gear Ratio (:1): 0.634
- Reverse Ratio (:1): – TBD –
- Clutch Size:
- Trans Power Take Off: , SAE 6-Bolt
- Trans PTO Access: , – TBD –
- Transfer Case Model:
- Transfer Case Gear Ratio (:1), High:
- Transfer Case Gear Ratio (:1), Low:
- Transfer Case Power Take Off: , 6-Bolt
- Cold Cranking Amps @ 0° F (Primary): 750, 825
- Cold Cranking Amps @ 0° F (2nd): 750, 825
- Cold Cranking Amps @ 0° F (3rd):
- Maximum Alternator Capacity (amps): 140
- Maximum Alternator Watts: – TBD –
- Total Cooling System Capacity: 20.8
- Engine Oil Cooler:
- Frame Type: Ladder-Type C-Section
- Sect Modulus Rails Only: 7.20
- Frame RBM: 316800
- Frame Strength: 44000
- Frame Thickness: 8.50 x 2.76 x 0.24
- Suspension Type – Front: Independent w/Tapered Leaf Springs
- Suspension Type – Rear: Independent w/Multi-Leaf Springs
- Spring Capacity – Front: 8440
- Spring Capacity – Rear: 14550
- Axle Type – Front: I-Beam
- Axle Type – Rear:
- Axle Capacity – Front: 7275
- Axle Capacity – Rear: 14550
- Axle Ratio (:1) – Front:
- Axle Ratio (:1) – Rear: 5.571
- Shock Absorber Diameter – Front: 42.0
- Shock Absorber Diameter – Rear: 42.0
- Stabilizer Bar Diameter – Front:
- Stabilizer Bar Diameter – Rear:
- Front Tire Order Code: 2TB
- Rear Tire Order Code: 3TB
- Spare Tire Order Code:
- Front Tire Size: 225/70R19.5
- Rear Tire Size: 225/70R19.5
- Spare Tire Size:
- Front Tire Capacity: 3640
- Rear Tire Capacity: 3415
- Spare Tire Capacity:
- Revolutions/Mile @ 45 mph – Front: 643
- Revolutions/Mile @ 45 mph – Rear: 643
- Revolutions/Mile @ 45 mph – Spare:
- Front Wheel Size: 19.5 x 6
- Rear Wheel Size: 19.5 x 6
- Spare Wheel Size:
- Front Wheel Offset: 127
- Rear Wheel Offset: 127
- Spare Wheel Offset:
- # of Bolt Holes – Front: 6
- # of Bolt Holes – Rear: 6
- # of Bolt Holes – Spare:
- Front Wheel Material: Steel
- Rear Wheel Material: Steel
- Spare Wheel Material:
- Steering Type: Pwr
- Steering Ratio (:1), On Center: – TBD –
- Steering Ratio (:1), At Lock: – TBD –
- Turning Diameter – Curb to Curb: 52.5
- Turning Diameter – Wall to Wall: 58.1
- Brake Type: Pwr
- Brake ABS System: 4-Wheel
- Brake ABS System (Second Line):
- Disc – Front (Yes or ): Yes
- Disc – Rear (Yes or ):
- Front Brake Rotor Diam x Thickness: 14.3 x – TBD –
- Rear Brake Rotor Diam x Thickness:
- Drum – Front (Yes or ):
- Front Drum Diam x Width:
- Drum – Rear (Yes or ): Yes
- Rear Drum Diam x Width: 14.6 x 5.91
- Fuel Tank Capacity, Approx: 30.0
- Aux Fuel Tank Capacity, Approx:
- Fuel Tank Location: Frame Rail
- Aux Fuel Tank Location:
- Front Head Room: 38.4
- Front Leg Room: 29.5
- Front Shoulder Room: 70.7
- Front Hip Room: 67.7
- Wheelbase: 176.0
- Length, Overall w/o rear bumper: 267.5
- Width, Max w/o mirrors: 81.3
- Height, Overall: 92.4
- Overhang, Front: 48.3
- Overhang, Rear w/o bumper: 43.1
- Front Bumper to Back of Cab: 70.9
- Cab to Axle: 153.5
- Cab to End of Frame: 196.6
- Ground to Top of Load Floor: – TBD –
- Ground to Top of Frame: 33.0
- Frame Width, Rear: 33.5
- Ground Clearance, Front: 7.5
- Ground Clearance, Rear: 7.5
- Front Frame Rating: – TBD –
- Seventh Gear Ratio (:1):
- Eighth Gear Ratio (:1):
- Ninth Gear Ratio (:1):
- Tenth Gear Ratio (:1):
- Eleventh Gear Ratio (:1):
- Twelfth Gear Ratio (:1):
- Thirteenth Gear Ratio (:1):
- Fourteenth Gear Ratio (:1):
- Fifteenth Gear Ratio (:1):
- Sixteenth Gear Ratio (:1):
- Seventeenth Gear Ratio (:1):
- Eighteenth Gear Ratio (:1):
- Nineteenth Gear Ratio (:1):
- Twentieth Gear Ratio (:1):
- Second Reverse Gear Ratio (:1):
- Third Reverse Gear Ratio (:1):
- Fourth Reverse Gear Ratio (:1):
- Fifth Reverse Gear Ratio (:1):
- Sixth Reverse Gear Ratio (:1):
- Body Weight (uncalculated): – TBD –
- Driver Weight: – TBD –
- Axle Ratio – Low Rear (:1):
- Driver Ratio: – TBD –
- Torque @ Clutch Engage: – TBD –
- Cab to Body: – TBD –
- Grade (%): – TBD –
- Frontal Area: – TBD –
- Governed Engine Speed (RPM): , 2750
- Torque Converter: 1.7639
- Front Wheel Description Cont.:
- Rear Wheel Description Cont.:
- Spare Wheel Description Cont.:
- Static Loaded Radius: – TBD –
- Front Bolt Pattern: 6 Hole JIS 8.75″
- Rear Bolt Pattern: 6 Hole JIS 8.75″
- Spare Bolt Pattern:
- Number Of Tires Front: 2
- Number Of Tires Rear: 4
- Number Of Tires Spare:
- Transmission Manufacturer: Aisin A465
- Transmission Type:
- Engine Series: 4HK1-TC
- Body Length Default Value: 20
- Engine Horsepower At RPM: 215 @ 2500
- Engine Horsepower At Max Speed RPM: – TBD –
- Max Speed For Gradeability: – TBD –
- Country of Origin: Japan Isuzu Incomplete Vehicle (Med./Heavy)
- Model Group: 5500
- Vehicle Segment: Chassis
- Vehicle Type: Standard Cab
- Engine Displacement Units: 5.2, 5.2
- Engine Camshaft: DOHC, DOHC
- Engine Block Type: iron, iron
- Engine Cylinder Count: 4, 4
- Engine Valve Count: 4, 4
